    0.5kw Electric External Concrete Vibrator Motor 8kg ZF150 380V / 50Hz

    Ask Lasest Price
    Brand Name : BESTA
    Model Number : ZF
    Certification : ISO9001
    Price : USD 20-200 per unit
    Supply Ability : 1000 units per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    0.5kw Electric External Concrete Vibrator Motor 8kg ZF150 380V / 50Hz

    Application:

    Widely used in construction, transportation, water conservancy, port, mine and metallurgy, etc. Used to consolidate cement and remove all the trapped air bubbles to give you the toughest cement possible. It can be adapted to every type of application, vibrator heads and shafts can be easily combined and rapidly exchanged to match the right equipment to the job.


    Our electric concrete vibrator motor concrete table vibrator with cheap price is a type of vibration motor, the eccentric block and a motor power fit each single or three phase asynchronous motor rotor shaft which are arranged on both ends, the centrifugal force generated by the rotation of the eccentric block vibration force, drive the whole body vibration. Concrete plate vibrator attached on the surface of concrete compaction, leveling instrument, operation at the bottom of the ZF plate vibrator installation of a plate, attached to the surface of plate and concrete, the excitation force is transmitted to the concrete mixture.


    ModelPower SupplyOutput PowerVibrating AmplitudeCentrifugal ForceCurrentWeight
     V/HzkWmmkNAkg
    ZFT3380/500.031.50.3-00.154.4
    ZFT9380/500.092.11-00.194.4
    ZF18380/500.182.310.377.5
    ZF25380/500.251.81.80.6712
    ZF55380/500.551.644.151.321.5
    ZF80380/500.822.61.7427
    ZF110380/501.124.32.5227
    ZF150380/501.52.48.33.1838
    ZF220380/502.22.2104.646
    ZF300380/5032.2146.457
