Brand Name : | BESTA |
Model Number : | CVM |
Certification : | CCC, ISO9001 |
Price : | USD 20-200 per unit |
Supply Ability : | 1000 units per month |
Delivery Time : | 30 days |
Our company has been accumulating all the experience in research &
development, manufacture, domestic & overseas sale with decades'
history. Owing to strong power in technique and innovation, and
obtained several state patents also the IPR of new products, such
as Low-noise Concrete Vibrator Shaft, Handhold Cleaner and
Double-use Power Trowel Machine, electric pressure washer, etc. We have possessed perfect and advanced processing & testing
equipments and approved by ISO9001 Quality Management System and
ISO14000 Environmental Management System. Most of our products have
got CCC, CQC, CE, ROHS, GS and all kinds of domestic and overseas
certificate.
Our main characteristic: Italy technology, the vibrator power could
be adjusted, F level isolation, IP65 import bearing, for small no.
model Alu. casting shell, for the big motor, it is ductile casting
made shell. Used for industrial machinery, engineering machinery,
mining equipment which will use the vibrator.
Product Highlights:
1. Motor made of 100% copper wire.
2. Can be triple phase or single.
3. 380V or 220v power supply to choose from, depends on the output power.
4. Cast iron Body.
5. Aluminum body also available, depends on the model.
Model | Power Supply | Output Power | Vibrating Amplitude | Centrifugal Force | Current | Weight |
V/Hz | kW | mm | kN | A | kg | |
CVM3 | 380/50 | 0.03 | 1.5 | 0.3-0 | 0.15 | 4.4 |
CVM9 | 380/50 | 0.09 | 2.1 | 1-0 | 0.19 | 4.4 |
CVM18 | 380/50 | 0.18 | 2.3 | 1 | 0.37 | 7.5 |
CVM25 | 380/50 | 0.25 | 1.8 | 1.8 | 0.67 | 12 |
CVM55 | 380/50 | 0.55 | 1.64 | 4.15 | 1.3 | 21.5 |
CVM80 | 380/50 | 0.8 | 2 | 2.6 | 1.74 | 27 |
CVM110 | 380/50 | 1.1 | 2 | 4.3 | 2.52 | 27 |
CVM150 | 380/50 | 1.5 | 2.4 | 8.3 | 3.18 | 38 |
CVM220 | 380/50 | 2.2 | 2.2 | 10 | 4.6 | 46 |
CVM300 | 380/50 | 3 | 2.2 | 14 | 6.4 | 57 |
![]() |
